Graco Magnum XR5 User Manual

14 309043
Accessories
Reversible Tip Selection Chart
Maximum tip hole size that each MAGNUM sprayer
supports is as follows:
XR5: New 0.015 in. (0.38 mm)
XR7: New 0.017 in. (0.43 mm)
XR9: New 0.019 in. (0.48 mm)
Tip
Part No.
Fan Width
12 in. (305 mm)
from surface Hole Size
RST411 8 to 10 in.
(203 to 254 mm)
0.011 in. (0.28 mm)
RST511 10 to 12 in.
(254 to 305 mm)
0.011 in. (0.28 mm)
RST313 6 to 8 in.
(152 to 203 mm)
0.013 in. (0.33 mm)
RST413 8 to 10 in.
(203 to 254 mm)
0.013 in. (0.33 mm)
RST415 8 to 10 in.
(203 to 254 mm)
0.015 in. (0.38 mm)
RST515 10 to 12 in.
(254 to 305 mm)
0.015 in. (0.38 mm)
RST417 8 to 10 in.
(203 to 254 mm)
0.017 in. (0.43 mm)
RST517 10 to 12 in.
(254 to 305 mm)
0.017 in. (0.43 mm)
RST519 10 to 12 in.
(254 to 305 mm)
0.019 in. (0.48 mm)
RST619 12 to 14 in.
(305 to 356 mm)
0.019 in. (0.48 mm)
Example: For an 8 to 10 in. (203 to 254 mm) fan width and
a 0.013 in. (0.33 mm) hole size order Part No. RST413.
Reversible tips must be installed in reversible tip guards.
Reversible Tip Guards
243000 11/16 in. (17 mm) thread
243001 7/8 in. (22 mm) thread
Reversible Tip Gaskets and Seat
243004 Includes
D 1 black rubber gasket
D 1 seat
Airless Spray Guns
243010 SG1 gun
With 413 reversible tip and guard
243011 SG2 metal gun
With 515 reversible tip and guard
243012 SG3 pro metal gun
With 517 reversible tip, guard, and Smooth
Glide swivel
Gun and Hose Kit
243105 Includes
D SG3 pro metal gun with 517
reversible tip, guard, and Smooth
Glide swivel
D Airless paint hose, 1/4 in. x 50 ft
(6.3 mm x 15.2 m)
Airless Paint Hoses, 3000 psi (21 MPa, 207 bar)
243020 Airless whip hose
3/16 in. x 4 ft (4.8 mm x 1.2 m)
Provides flexibility and increases operator
control of gun
243022 Airless paint hose
1/4 in. x 25 ft. (6.3 mm x 7.6 m)
With 1/4 in. (6.3 mm) connectors
243024 Airless paint hose
1/4 in. x 50 ft (6.3 mm x 15.2 m)
With 1/4 in. (6.3 mm) connectors
243025 Hose connector
1/4 in. x 1/4 in. (6.3 mm x 6.3 mm)
Tip Extensions
Attach to SG1, SG2, and SG3 guns to extend reach
when spraying ceilings, overhangs, and decks
243040 10 in. (25 cm)
243041 15 in. (38 cm)
243042 20 in. (50 cm)
243043 30 in. (75 cm)
Heavy-Duty Extensions
Attach to SG1, SG2, and SG3 guns to extend reach
when spraying or pressure rolling
With 7/8 in. (22 mm) thread
243051 20 in. (50 cm)
243052 40 in. (100 cm)
