Graco Magnum XR7 User Manual

309043 13
Technical Data
MAGNUM XR5 MAGNUM XR7 MAGNUM XR9
Working pressure range 0 to 2800 psi
(0 to 19 MPa, 0 to 193 bar)
0 to 3000 psi
(0 to 21 MPa, 0 to 207 bar)
0 to 3000 psi
(0 to 21 MPa, 0 to 207 bar)
Electric motor (open-frame,
permanent magnet DC)
5.8 Amp 5.8 Amp 4.9 Amp
Operating horsepower 5/8 3/4 7/8
Maximum delivery (with tip) 0.24 gpm (0.91 lpm) 0.31 gpm (1.17 lpm) 0.38 gpm (1.44 lpm)
Paint hose 25 ft (7.6 m) x 1/4 in. 50 ft (15.2 m) x 1/4 in. 50 ft (15.2 m) x 1/4 in.
Maximum tip hole size 0.015 in. (0.38 mm) 0.017 in. (0.43 mm) 0.019 in. (0.48 mm)
Weight, sprayer only 21 lb (10 kg) 31 lb (14 kg) 35 lb (16 kg)
Weight, sprayer, hose, & gun 24 lb (11 kg) 36 lb (17 kg) 40 lb (18 kg)
Dimensions 13.75 in. (34.9 cm) L
11 in. (27.9 cm) W
17 in. (43.2 cm) H
19.5 in. (49.5 cm) L
17.25 in. (43.8 cm) W
40.75 in. (103.5 cm) H
Height with folded handle is
26 in. (66 cm)
19.5 in. (49.5 cm) L
19 in. (48.3 cm) W
40 in. (101.6 cm) H
Height with folded handle is
26 in. (66 cm)
Power cord 16 AWG, 3 wire, 6 ft (1.8 m) 16 AWG, 3 wire, 6 ft (1.8 m) 16 AWG, 3 wire, 10 ft (3 m)
Pump inlet fitting 3/4 in. internal thread (standard garden hose thread)
Fluid outlet fitting 1/4 npsm external thread
Inlet screen on suction tube 14 mesh (1300 micron)
Wetted parts, pump & hose stainless steel, brass, leather, ultra-high molecular weight polyethylene (UHMWPE), carbide,
nylon, PVC, zinc-aluminum alloy
Wetted parts, gun SG1: aluminum, brass, carbide, nylon, plated steel, stainless steel, UHMWPE
SG2 / SG3: aluminum, brass, carbide, nylon, plated steel, stainless steel, UHMWPE, zinc
Generator requirement 1500 Watt minimum
Electrical power requirement 120V AC, 60 Hz, 1 phase, 15A
Storage temperature range * { –30_ to 160_ F (–35_ to 71_ C)
Operating temperature
range **
40_ to 115_ F (4_ to 46_ C)
* When pump is stored with non-freezing fluid.
{ Damage to plastic parts may result if impact occurs in low-temperature conditions.
* * Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
