Grant 2020 Series User Manual

SQ2020/40 18108 Version 17
Page 14
www.grantinstruments.com
EN
6.2 Control panel menu
Detailed below is a basic explanation of the top menu structure. For more information on
the whole menu structure please refer to the Help->Help Content->Loggers within
SquirrelView.
6.2.1 Log Control
In this menu you can Arm (activate), Pause
and Continue or Disarm (deactivate) the
logger.
6.2.2 Meter
Here you can view each channel in Real
Time (at 1-2Hz). Use the Enter key for a
graphical view of a channel.
6.2.3 Status
The Status menu gives you access to
information relating to the logger such as
available memory and power supply
voltage. You can also override the alarm
outputs from here.
6.2.4 Setup
This contains menus for setting up
Language, Time & Date, basic Channel
Setup, storing and recalling setups and
delayed starts.
See 6.3 for more details on basic setup
6.2.5 Data Files
This menu allows you to copy data files to
an external memory card (if fitted) and
delete the data files held within the
logger’s memory.
6.2.6 Tools
The Tools menu contains maintenance
type functions such as querying the
software version or IP address of the
logger, performing a self test and resetting
the logger.

Grant 2020 Series Specifications

General

Category	Data Loggers
Interface	USB
Power Supply	Internal batteries, USB or external power supply
Temperature Range	-35°C to +85°C (-31°F to +185°F) (Logger dependent)
Accuracy	Logger dependent, refer to datasheet
Operating Temperature	-35°C to +85°C (-31°F to +185°F) (Logger dependent)
Measurement Parameters	Voltage, current, temperature, humidity, resistance, strain, events/state, count
Data Logging Interval	User selectable from 1 second to 12 hours
Dimensions	Logger dependent, refer to datasheet
Weight	Logger dependent, refer to datasheet
Battery Life	Up to 5 years (dependent on logging rate and logger model)
