Grant 2020 Series User Manual

SQ2020/40 18108 Version 17
Page 2
www.grantinstruments.com
EN
A) SQ2020/2040 Logger
B) USB drive containing software (SQA100)
C) Getting Started manual (this booklet)
D) USB Cable (LC77)
E) Mounting bracket/stand for logger (WB6)
F) Batteries, 6 x AA
G) Current shunt resistors for 4 to 20mA inputs, 10R x 4 (CS202)
H) Connectors: 6 way x 4 (18097), 4 way (13975), 3 way
(14174), with cable ties
Note: 2040 Logger is supplied with 4 extra 6 way connectors
as above (18097).
Wi-fi version also contains an antenna.
1. Hardware Checklist
A
B
C
D
E
F
G
H

Grant 2020 Series Specifications

General

Category	Data Loggers
Interface	USB
Power Supply	Internal batteries, USB or external power supply
Temperature Range	-35°C to +85°C (-31°F to +185°F) (Logger dependent)
Accuracy	Logger dependent, refer to datasheet
Operating Temperature	-35°C to +85°C (-31°F to +185°F) (Logger dependent)
Measurement Parameters	Voltage, current, temperature, humidity, resistance, strain, events/state, count
Data Logging Interval	User selectable from 1 second to 12 hours
Dimensions	Logger dependent, refer to datasheet
Weight	Logger dependent, refer to datasheet
Battery Life	Up to 5 years (dependent on logging rate and logger model)
