33506_33508_33512_33516_T1V2sh
Special features of the GR-24 and GR-32 HoTT receiver
Connection 7
• SERVO
Input 7 is suitable for operating RC components.
• SUMDIN
Port 7 is suitable as input to a SUMD signal provided by receivers
GR-16, GR-24 or GR-32.
ശ If a GR-16, GR-24, GR-32 receiver is set to „SUMD“, as
described below under „Input 8“ (GR-16 and GR-24) or
„Input S“ (GR-32), or any combination of these combined
with a receiver set to „SUMDIN“, creates a simple satellite
connection with the receiver set to SUMDIN as the primary
receiver.
ശ If two of these receivers are set on SUMDIN as well as on
SUMD and connected crosswise with two satellite cables, a
reciprocal satellite connection is created:
SUMD SUMDIN
GR-16 HoTT and GR-24 HoTT CH8 CH7
GR-32 HoTT S CH7
Connection 8 (GR-24)
Connection S (GR-32)
CH OUTPUT TYPE
Depending on the settings in the “CH OUTPUT TYPE” line of the “RX
SERVO TEST” page of the telemetry menu, the output 8 can be used
for different scopes. Carry out the changeover as described in the
instructions for the transmitter or the SMART-BOX.
By setting ...
• ONCE or SAME
to connect a servo, ESC, Gyro, etc...
ശ ONCE
The servo connections of the receiver are actuated sequen-
tially. The receiver power supply is less stressed.
ശ SAME
The servo connections of the receiver are actuated in a 4 pcs
block synchronic. The simultaneous start-up of up to four ser-
vos has a noticeably higher load on the receiver power sup-
ply.
• SUMO, SUMI, SUMD, SUMD3 or SBUS
RX CURVE V7.07
TYPE : A
CURVE1 CH : 02
TYPE : A
CURVE2 CH : 03
TYPE : B
CURVE3 CH : 04
7CH FUNCTION:SERVO
