Gravely 988075 - Key Switch; Pto Switch

9 - 38
Electric Start Models
OFF
M
G
S2
B
S1
A
RUN
M
G
S2
B
S1
A
START
M
G
S2
B
S1
A
Key Switch
(036023)
Relay
(03042800)
87
87A
86 85
30
NOT ENERGIZED
87
87A
86 85
30
ENERGIZED
39
471
DISENGAGED
(down position)
39
471
ENGAGED
(up position)
PTO Switch
(01545600)
HAND
ON HANDLE
Bale Switch
(09251900)
HAND
OFF HANDLE
1
2
1
2
l
1
2
DISENGAGED
(button out)
1
2
ENAGED
(button in)
Transmission Neutral Switch
(034640)
The diagrams below show the various states of connection for electrical components.
The solid lines on switches show continuity.
NOTE: All switches are viewed from the rear.
PG0840
