Gravely 991160 - Assembly

EN - 10
1. Remove crate top and sides.
2. Remove plastic bag from around unit and
discard.
Models 991152, 991154, 991156, 991160,
991162, 991164, 991166
3. Remove and retain front seat hardware.
See Figure 3.
4. Align rear seat hardware with key slots in
seat plate. See Figure 4.
5. Adjust seat to forward-most position. See
Adjust Seat on page 24.
See Figure 5.
6. Rotate seat forward.
7. Reinstall hardware removed in step 3.
All Models
See Figure 6.
8. Remove plastic boot from negative
battery terminal and discard.
9. Remove hardware from negative (black)
battery cable. DO NOT discard hardware.
10. Secure negative battery cable to negative
(open) battery terminal with hardware
removed in previous step.
ASSEMBLY
WARNING: AVOID INJURY.
Read and understand the
entire Safety section before
proceeding.
Figure 3
Figure 4
Figure 5
Figure 6
