EN - 17
Lower Center Bar
See Figure 19.
1. Remove hairpins from lock pins and
remove lock pins from hinge plate.
2. Lower center bar and secure with lock
pins and hairpins.
IMPORTANT: Return center bar to the raised
position when clear of obstacles.
START THE ENGINE
1. Push PTO knob down to off position.
2. Move steering levers to neutral position.
3. Engage parking brake.
4. Models 991160, 991162, 991164, 991166,
991192, 991194, 991196, 991230,
991232, 991234: If engine is cold, pull
choke knob up to on position. If engine is
warm or hot, turn choke off.
5. Set throttle to slow speed.
6. Insert ignition key and turn to start
position. Release key when engine starts.
IMPORTANT: Do not operate the starter for
more than 10 seconds at a time. If the engine
does not start, allow a 60-second cool down
period between starting attempts.
7. Models 991160, 991162, 991164, 991166,
991192, 991194, 991196, 991230,
991232, 991234: If choke is on, wait a
few seconds after engine starts and then
push choke knob down to off position.
WARNING: AVOID INJURY.
Lower the center bar only
when needed to drive under
an object. There is no rollover
protection with the center bar
in the lowered position. DO
NOT wear seatbelt when
ROPS is in lowered position.
Figure 19
Lowered Position With
Bagger Installed
Lowered Position With
No Bagger Installed
