THE MANUAL
Before operation of unit, carefully and completely read your
manuals. The contents will provide you with an understanding of
safety instructions and controls during normal operation and
maintenance.
All reference to left, right, front, or rear are given from operator
sitting in the operation position and facing the direction of forward
travel.
SERVICE AND REPLACEMENT PARTS
When ordering publications, replacement parts,
or making service inquiries, know the Model
and Serial numbers of your unit and engine.
Numbers are located on the product
registration form in the literature package. They
are printed on a serial number label, located on
the frame of your unit (Figure 1).
• Record Unit Model and Serial numbers here.
• Record Engine Model and Serial numbers here.
PRODUCT REGISTRATION
The Gravely dealer must register the product at the time of
purchase. Registering the product will help the company process
warranty claims or contact you with the latest service information.
All claims meeting requirements during the limited warranty
period will be honored, whether or not the product registration
card is returned. Keep a proof of purchase if you do not register
your unit.
Customer Note: If the Dealer does not register your product,
please fill out, sign and return the product registration card to
Gravely or go to www.gravely.com on the internet.
UNAUTHORIZED REPLACEMENT PARTS
Use only Gravely replacement parts. The replacement of any part
on this equipment with anything other than a Gravely authorized
replacement part may adversely affect the performance,
durability, and safety of this unit and may void the warranty.
Gravely disclaims liability for any claims or damages, whether
regarding warranty, property damage, personal injury or death
arising out of the use of unauthorized replacement parts.
NOTE: To locate your nearest Gravely Dealer, go to
www.gravely.com on the internet.
DISCLAIMER
Gravely reserves the right to discontinue, change, and improve
its products at any time without public notice or obligation to the
purchaser. The descriptions and specifications contained in this
manual were in effect at printing. Equipment described within this
manual may be optional. Some illustrations may not be
applicable to your unit.
DEALER DELIVERY
Dealer should:
1. Test brakes after unit is assembled to be sure adjustment
has not been disturbed in shipment (See Parking Brake
Interlock System on page 8). Wheel brakes are properly
adjusted at factory.
2. Check the safety interlock system to make sure that it is
functioning properly. With operator on seat, unit must not
start unless steering levers are in neutral (N) and Power
Takeoff (PTO) is disengaged (Off). Engine must stop if
operator leaves seat when steering levers are in any drive
position or PTO is engaged (On). See Safety Interlock
System on page 8.
3. Fill out a Product Registration Card and return the card
to Gravely or go to www.gravely.com.
4. Explain Limited Warranty Policy.
TABLE OF CONTENTS
INTRODUCTION
Transfer
model &
serial
number
label from
product
registration
here.
Figure 1
Serial Number Label
OF1612
Copyright 2006 Ariens Company
