SYSTEM PARTS
Indoor unit
Part Name
1. Power Supply and
Communication Wires
2. Drain Pipe
3. Liquid Pipe
4. Decorative Discharge Air
Grille (sold separately)
5. Gas Pipe
6. Wired Tether Controller
7. Remote Controller
8. Service Cover
9. Power Supply and
Communication Wires
10. Front Panel
11. Outdoor Power Supply
12. Liquid Pipe
13. Gas Pipe
14. Drain Hose
Outdoor Unit
Air outlet
Air inlet
1
2
5
4
3
67
Air outlet
Air inlet
14
12
11
10
The refrigerant pipe, drain pipe and electrical wiring for this unit should be
installed by a qualified HVAC professional only.
CAUTION
98
13
5
Part Numbers Description
CASGRILLE1SM Decorative Grille for 12,000 & 18,000 BTU Cassettes
CASGRILLE1LG Decorative Grille for 24,000 BTU Cassette
MC20700140 XK-19 Wired Tether Controller with touch buttons.
