Gree FGR30/BNa-M User Manual

5
Duct Type Split Air Conditioner
Service Manual
PRODUCT
4 PRODUCT DATA
4.1 Product Data at Rated Condition
Models
Indoor
Unit
FGR/BNa-M(I) FGR/CNa-M(I) FG/BNa-M(I) FG/CNa-M(I)
20 25 20 25
Outdoor
Unit
FGR/BNa-M(O) FGR/CNa-M(O) FGR/BNa-M(O) FGR/CNa-M(O)
20 25 20 25
Nominal Capacity
At Rated ESP
Cooling
Btu/h 68000 83598 68000 83598
kW 20 24.5 20 24.5
Heating
Btu/h 75000 93834 / /
kW 22 27.5 / /
Power Supply V/Ph/Hz 380-415/3/50 380-415/3/50
Power Consumption
Cooling
kW
8.4 9.8 8.4 9.8
Heating 7 9.0 / /
Running Current
Cooling
A
15.3 19.2 15.3 19.2
Heating 13.2 17.7 / /
Refrigerant Type R410a R410a
Refrigerant Charge kg 5.3 6.7 5.3 6.7
Indoor Unit
Power Supply V/Ph/Hz 380-415/3/50 380-415/3/50
Fan
Type Centrifugal / Belt Drive Centrifugal / Belt Drive
Air ow
CFM 2380 2825 2380 2825
m
3
/h 4000 4800 4000 4800
Input Power W 1100 1500 1100 1500
Running Current A 2 3.4 2 3.4
Rated ESP
in.wg 0.8 0.44 0.8 0.44
Pa 200 110 200 110
Fan Motor Protection - Overload protection Overload protection
Sound Pressure Level
(H/M/L/SL)
dB(A) 56 54 56 54
Coil
Tube
Material - Inner Groove Copper Tube Inner Groove Copper Tube
Diameter mm 7 7.94 7 7.94
Fin
Material - Aluminum Aluminum
No.of Rows/
FPI
- 3/16 3/16 3/16 3/16
Coil Area Sqm 0.766 0.63 0.766 0.63
Dimensions
(Outline/
Package)
Height
mm
389/400 500/673 389/470 500/673
Width 1463/1540 1500/1840 1463/1540 1500/1840
Depth 799/880 1000/1200 799/880 1000/1200
Weight(Net/Gross) kg 86/109 150/200 86/109 150/200
System Operation Control -
Wired Control with LED Display
+ Wireless Controller
Wired Control with LED Display
+ Wireless Controller
Condensate Drainage(O.D) mm 25.4 25.4
Air Filter - Standard Washable and Synthetic Standard Washable and Synthetic
To be continued

Gree FGR30/BNa-M Specifications

General

Brand	Gree
Model	FGR30/BNa-M
Category	Air Conditioner
Language	English
