Floor Ceiling T
ype Fan
Coil Unit Service Manual
3 Power distribution
The logic in electric control box is as following:
Mainboard Control
Power supply
Transformer
Temp. sensor
Reveiver
Motor
Swing
Motor
4 Wiring diagram
FP-34WM-K; FP-51WM-K; FP-136WM-K; FP-170WM-K; FP-204WM-K.
Power
XT
L
N
PE
BN
WH
RD
9BU
COMP
4RD
R:20K
RT1
ROOM TEMP.
SENSOR
X11
ROOM
CN1
X9
X8
X3
X4
X2
R:15K
R:10K
6BU
(RIGHT)
WH
RD
BN
YEGN
PE
X2
X12
FUT:3.15A
250V~50T
BK
YE
BU
(LEFT)
7RD5
YE
R:20K
OROOM
EXHUST
OTUBE
CN3
X4
X3
X10
TUBE
L
KM
X22
X 19(LPP)
10BU
WA
TER
VA
LV
E
X 20(OVC)
31
33
