Gree FP-34WA/G-K User Manual

Enginnering Data
30
FP-34WA(H)/G Part Lists:
No
Name
Code
Quantity
1
Water Tray Assy
81211150017
1
2
Base Plate
02225200066
1
3
Surface-Cooler Assy
01126000766/01126000767
1
4
Cover Plate Sub-Assy
01265200190
1
5
End-Plate
02226001407
2
6
Surface Cooler Cover Sheet
01496000327
1
7
Motor Retaining Plate
01845200033
1
8
Propeller Housing(Lower)
26906000024
1
9
Centrifugal Fan
10456000102
1
10
Centrifugal fan assy
01396001421
1
11
Propeller Housing(Upper)
26906000023
1
12
Fan Motor
150195264/15707301
1
13
Hoop
70819521
4
14
Bar Clasp
70819522
1
15
Motor Support
01806000437
1
16
Side Plate of the Air Outlet
02226001530
1
17
Divided ( collective) water joint support
01846000179
1
18
Electric Box Assy
01396001537
1
19
Electric Box Cover Plate
01426000259
1
20
Wire Clamp
71010003
1
21
Cable Cross Loop
26900000008
2
22
Insulation Gasket
70410503
1
23
Terminal Board
4201026502
1
24
Electric Base Plate
01426000258
1
25
Capacitor CBB61
33010089
1
FP-34WA(H)S/G Part Lists:
No
Name
Code
Quantity
1
Water Tray Assy
81211150017
1
2
Base Plate
02225200066
1
3
Surface-Cooler Assy
01126000741/01126000768
1
4
Cover Plate Sub-Assy
01265200190
1
5
End-Plate
02226001407
2
6
Surface Cooler Cover Sheet
01496000327
1
7
Motor Retaining Plate
01845200033
1
8
Propeller Housing(Lower)
26906000024
1
9
Centrifugal Fan
10456000102
1
10
Centrifugal fan assy
01396001421
1
11
Propeller Housing(Upper)
26906000023
1
12
Fan Motor
150195264/15707301
1
13
Hoop
70819521
4
14
Bar Clasp
70819522
1
15
Motor Support
01806000437
1
