Gree GDN06AJ-D4EBC1A Service Manual

2
Technical Information
Service Manual
2.Specications
Model
1.GDN12AJ-K4EBC1A
2.GDN12AJ-K4EBC1B
GDN16AJ-K4EBC1A
Product Code
1.CK051012901/CK051012902
2.CK051019102
CK051013001
CK051013003
Power Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Rated Dehumidifying Volume L/h 0.23 0.4
Power Input W 230 295
Power Current A 1.3 1.3
Set Humidity Range % 35~80 35~80
Air Flow Volume(H/M/L) m
3
/h 115/-/100 115/-/100
Fan Motor Speed (H/M/L) r/min 1100/-/950 1100/-/950
Output of Fan Motor W 4 4
Fan Motor Capacitor μF 1.5 1.5
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ180X54.5 Φ180X54.5
Throttling Method Capillary Capillary
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 43/-/41 45/-/43
Sound Power Level ((H/M/L) dB (A) 53/-/51 53/-/51
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 3 3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 1.8 1.8
Dimension (WXHXD) mm 353X496X225 353X496X225
Dimension of Carton Box (LXWXH) mm 393X271X510 393X271X510
Dimension of Package (LXWXH) mm 396X274X525 396X274X525
Application Area m
2
15 20
Net Weight kg 11 13.5
Gross Weight kg 12 14.5
Refrigerant R134a R134a
Refrigerant Charge kg 0.09 0.17
Bucket Capacity L 3/3.5 3/3.5
Control Type Electronic Electronic
Evaporator
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 1-1.4 2-1.6
Coil Length (LXDXW) mm 210X12.7X152.4 210X25.4X152.4
Condenser
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ7
Rows-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 210X22.8X152.4 210X25.4X152.4
Compressor
Compressor Manufacturer/Trademark
Shanghai Hitachi Electrical
Appliances Co.,Ltd/HIGHLY
Shanghai Hitachi Electrical
Appliances Co.,Ltd/HIGHLY
Model BSA418CV-R1AUN 39E0G3HR&F^YA
Type Rotary Rotary
Power Input W 213 265
Overload Protector URP-191-78 or equivalent UP3-106
L.R.A. A 3.4 5.5
Working Current A 1.1 1.2
The above data is subject to change without notice; please refer to the nameplate of the unit.
