Gree GDN10AH-K4EBB1C User Manual

2
Service Manual
Installation and Maintenance
2.Specications
The above data is subject to change without notice; please refer to the nameplate of the unit.
Model GDN10AH-K4EBB1C GDN12AH-K4EBB1C
Product Code CK051026100 CK051026200
Power Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Rated Dehumidifying Volume L/h 0.17 0.18
Power Input W 220 220
Power Current A 1.20 1.20
Set Humidity Range % 35~80 35~80
Air Flow Volume(H/M/L) m
3
/h 150/120/100 150/120/100
Fan Motor Speed (H/M/L) r/min 930/800/650 930/800/650
Output of Fan Motor W 6 6
Fan Motor Capacitor μF 1.0 1.0
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ180X76.5 Φ180X76.5
Throttling Method Capillary Capillary
Fuse A 3.15 3.15
Sound Pressure Level (H/M/L) dB (A) 43/41/39 43/41/39
Sound Power Level ((H/M/L) dB (A) 53/51/49 53/51/49
Climate Type T1 T1
Isolation I I
Moisture Protection IPX0 IPX0
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 1.7 1.7
Permissible Excessive Operating Pressure for the
Suction Side
MPa 0.6 0.6
Dimension (WXHXD) mm 343X525X260 343X525X260
Dimension of Carton Box (LXWXH) mm 391X310X569 391X310X569
Dimension of Package (LXWXH) mm 394X313X584 394X313X584
Application Area m
2
14 14
Net Weight kg 13 13
Gross Weight kg 14.5 14.5
Refrigerant R134a R134a
Refrigerant Charge kg 0.08 0.09
Bucket Capacity L 4.0/4.6 4.0/4.6
Control Type Electronic Electronic
Evaporator
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 1-1.3 1-1.3
Coil Length (LXDXW) mm 235X12.7X190.5 235X12.7X190.5
Condenser
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Rows-n Gap mm 1-1.4 1-1.4
Coil Length (LXDXW) mm 235X12.7X190.5 235X12.7X190.5
Compressor
Compressor Manufacturer/Trademark
Shanghai Hitachi Electrical
Appliances Co.,Ltd/HIGHLY
Shanghai Hitachi Electrical
Appliances Co.,Ltd/HIGHLY
Model BSA418CV-R1AUA BSA418CV-R1AUA
Type Rotary Rotary
Power Input W 213 213
Overload Protector URP-191-78 URP-191-78
L.R.A. A 3.4 3.4
Working Current A 1.2 1.2
