Notes:
a. The rated cooling capacity data is measured under the following work condition: Indoor Temperature is 27℃
DB, 19℃WB. Outdoor Temperature is 35℃DB. The rated heating capacity data is measured under the following
work condition: Indoor Temperature is 20℃DB. Outdoor Temperature is 7℃DB, 6℃WB.
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
4.2 Product Data of Indoor Unit
4.2.1 Wall mounted type
¾ Hansol
Model
GWH(07)TA-K3DN
A1E/I
GWH(09)TA-K3DN
A1E/I
GWH(12)TB-K3DN
A1E/I
Cooling kW 2.1 2.5 3.50
Capacity
Heating kW 2.6 2.75 3.65
Power supply V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Motor power input kW 0.029 0.029 0.029
m3/h 550 550 770
Air flow volume
CFM 324 324 430
Sound pressure level
(SH/H/MH/M/ML/L/SL)
dB(A) 41/36/34/32/28/24/21 41/36/34/32/28/24/21 43/36/34/32/28/24/21
Output kW 0.015 0.015 0.015
Fan motor
Running
current
A 0.07 0.07 0.07
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connecting
pipe
Connection method Flare Connection Flare Connection Flare Connection
External dia. mm Φ20 Φ20 Φ20
Drain pipe
Thickness mm 1.5 1.5 1.5
Outline
dimension
W×D×H mm 806×209×292 806×209×292 866×209×292
Package
dimension
W×D×H mm 888×297×377 888×297×377 945×297×377
Net Weight/Gross weight kg 10.5/13.0 10.5/13.0 11.0/13.5
20'GP 266 266 252
40' GP 553 553 518
Loading quantity
40' HQ 632 632 592
