Gree GMV-615WM/B-X Service Manual

GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
9
IV. Electrical Parameters
1. Power Cable Wire Gauge and Circuit Breaker Selection
Model
Basic models
Circuit
breaker
capacity
(A)
Circuit breaker
capacity for
combined units
(A )
Wire size of
power supply
(mm
2
)
Wire size of combined
uni (mm
2
)
GMV-224WM/B-X
GMV-224WM/B-X
20
20
2.5
2.5
×
5
GMV-280WM/B-X
GMV-280WM/B-X
25
25
2.5
2.5
×
5
GMV-335WM/B-X
GMV-335WM/B-X
32
32
4.0
4.0
×
5
GMV-400WM/B-X
GMV-400WM/B-X
40
40
6.0
6.0
×
5
GMV-450WM/B-X
GMV-450WM/B-X
40
40
6.0
6.0
×
5
GMV-504WM/B-X
GMV-504WM/B-X
50
50
10
10
×
5
GMV-560WM/B-X
GMV-560WM/B-X
63
63
10
10
×
5
GMV-615WM/B-X
GMV-615WM/B-X
63
63
10
10
×
5
GMV-680WM/B-X
280+400
63
25 + 40
2.5 + 6.0
2.5
×
5 + 6.0
×
5
GMV-730WM/B-X
280+450
63
25 + 40
2.5 + 6.0
2.5
×
5 + 6.0
×
5
GMV-785WM/B-X
280+504
80
25 + 50
2.5 + 10
2.5
×
5 + 10
×
5
GMV-850WM/B-X
280+560
80
25 + 63
2.5 + 10
2.5
×
5 + 10
×
5
GMV-900WM/B-X
280+615
80
25 + 63
2.5 + 10
2.5
×
5 + 10
×
5
GMV-950WM/B-X
335+615
80
32 + 63
4.0 + 10
4.0
×
5 + 10
×
5
GMV-1010WM/B-X
400+615
100
40 + 63
6.0 + 10
6.0
×
5 + 10
×
5
GMV-1065WM/B-X
450+615
100
40 + 63
6.0 + 10
6.0
×
5 + 10
×
5
GMV-1130WM/B-X
504+615
125
50 + 63
10 + 10
10
×
5 + 10
×
5
GMV-1180WM/B-X
560+615
125
63 + 63
10 + 10
10
×
5 + 10
×
5
GMV-1235WM/B-X
615+615
125
63 + 63
10 + 10
10
×
5 + 10
×
5
GMV-1300WM/B-X
280+450+560
125
25 + 40 + 63
2.5 + 6.0 + 10
2.5
×
5 + 6.0
×
5 +10
×
5
GMV-1350WM/B-X
280+450+615
125
25 + 40 + 63
2.5 + 6.0 + 10
2.5
×
5 + 6.0
×
5 + 10
×
5
GMV-1405WM/B-X
335+450+615
125
32 + 40 + 63
4.0 + 6.0 + 10
4.0
×
5 + 6.0
×
5 + 10
×
5
GMV-1456WM/B-X
280+560+615
160
25 + 63 + 63
2.5 + 10 + 10
2.5
×
5 + 10
×
5 + 10
×
5
GMV-1512WM/B-X
280+615+615
160
25 + 63 + 63
2.5 + 10 + 10
2.5
×
5 + 10
×
5 + 10
×
5
GMV-1570WM/B-X
335+615+615
160
32 + 63 + 63
4.0 + 10 + 10
4.0
×
5 + 10
×
5 + 10
×
5
GMV-1650WM/B-X
400+615+615
160
40 + 63 + 63
6.0 + 10 + 10
6.0
×
5 + 10
×
5+ 10
×
5
GMV-1700WM/B-X
450+615+615
160
40 + 63 + 63
6.0 + 10 + 10
6.0
×
5 + 10
×
5 + 10
×
5
GMV-1750WM/B-X
504+615+615
160
50 + 63 + 63
10 + 10 +10
10
×
5 + 10
×
5 + 10
×
5
GMV-1800WM/B-X
560+615+615
180
63 + 63 + 63
10 + 10 +10
10
×
5 + 10
×
5 + 10
×
5
GMV-1845WM/B-X
615+615+615
180
63+63+63
10+10+10
10
×
5+10
×
5+10
×
5
GMV-1908WM/B-X
280+450+560+615
180
25+40+63+63
2.5+6.0+10+10
2.5
×
5+6.0
×
5+10
×
5+10
×
5
GMV-1962WM/B-X
280+504+560+615
180
25+50+63+63
2.5+10+10+10
2.5
×
5+10
×
5+10
×
5+10
×
5
GMV-2016WM/B-X
280+560+560+615
200
25+63+63+63
2.5+10+10+10
2.5
×
5+10
×
5+10
×
5+10
×
5
