Multi Variable Air Conditioners Floor and Ceiling Type Indoor Unit
3
Any personal injury or property loss caused by improper installation, improper debug,
unnecessary repair or not following the instructions of this manual should not be the responsibility of
Gree Electric Appliances, Inc. of Zhuhai.
2 Product Introduction
2.1 Names of Key Components
12
3
4
56
No.
① ② ③ ④ ⑤ ⑥
Name Drainage Pipe
Connection
Pipe
Air Inlet Grille
(With Filter)
Louver Main Unit Display board
2.2 Rated Working Condition
Indoor Side Condition Outdoor Side Condition
Dry Bulb Temp °C Wet Bulb Temp °C Dry Bulb Temp °C Wet Bulb Temp °C
Rated Cooling 27 19 35 24
Rated Heating 20 15 7 6
