Installation in a double-hung sash window

nut

spring washer

washer

screws

washer

bolt

support

rain shield

5. Fix the rain shield on the support with nuts, spring washer, washer and bolt.

6. Cut the sponge B to a proper length and attach it to the window sash.

7. Attach the window panel to the window stool.

7.1 If the inner width of the window is less than 20.5"(520mm)

The window panel cannot be installed in windows less than 20.5"(520mm) wide.

(1) Remove the adjustment panel from the window panel, and cut the window

panel to the same width as the window.

(2) Open the window sash and place the window panel on the window stool.

(3) Secure the window panel to the window stool with screws.

sponge B (adhesive)

Cut

adjustment panel

Window panel assemble

Window panel

<20.5"

Window stool
