Disassemble heat discharge pipe
1. 2. Remove heat discharge pipe
from protective grille sub-assy.
upwards
clasp
disassemble
Heat discharge pipe
Anticlockwise
Join A
joint A
Remove joint A:
Press the clasp and lift joint A upwards to
remove it.
Installation and Disassembly of Heat Discharge Pipe
32
Operation Test
Put through the power supply and then press ON/OFF button on remote contro-
ller to start the unit.
Press mode button to select auto, cooling, drying, fan or heating function, and
then check if the unit operates normally.
If ambient temperature is below 61°F(16°C), the unit can't operate in cooling mode.
