Installation and Disassembly of Heat Discharge Pipe
Note of Installingheat discharge pipe
correct
wrong
●
The length of the heat discharge pipe is less than 40 inchs. It is recommended to
use it with shortest length.
When installing,heat discharge pipe should be as flat as possible. Don’t prolong
the pipe or connect it with other heat discharge pipe.
31
The discharge pipe is suggested to be installed according to below figure by the manufacturer.
User can adjust the installation method of the discharge pipe basing on the requirement, while
the similar installation methods as below which will lead to unsmoothly air-out are not allowed.
under 51 inchs
about 24 inchs
