3.3.2 Indoor unit
Table 1-4-2 Electrical Data of Indoor Unit
Model
Power Supply
Fan Motor FLA
Fuse/Breaker Capacity
Min. Power Supply Cord
V/Ph/Hz
A
A
mm
2
GFH09K3FI
220-240,1,50
<1
5/6
1.0
GTH09K3FI
220-240,1,50
<1
5/6
1.0
GFH12K3FI
220-240,1,50
<1
5/6
1.0
GTH12K3FI
220-240,1,50
<1
5/6
1.0
GKH12K3FI
220-240,1,50
<1
5/6
1.0
GFH18K3FI
220-240,1,50
<1
5/6
1.0
GTH18K3FI
220-240,1,50
<1
5/6
1.0
GKH18K3FI
220-240,1,50
<1
5/6
1.0
GFH24K3FI
220-240,1,50
<1
5/6
1.0
GTH24K3FI
220-240,1,50
<1
5/6
1.0
GKH24K3FI
220-240,1,50
<1
5/6
1.0
GFH30K3FI
220-240,1,50
<1
5/6
1.0
GTH30K3FI
220-240,1,50
<1
5/6
1.0
GKH30K3FI
220-240,1,50
<1
5/6
1.0
GFH36K3FI
220-240,1,50
<1
5/6
1.0
GTH36K3FI
220-240,1,50
<1
5/6
1.0
GKH36K3FI
220-240,1,50
<1
5/6
1.0
GFH42K3FI
220-240,1,50
<1
5/6
1.0
GTH42K3FI
220-240,1,50
<1
5/6
1.0
GKH42K3FI
220-240,1,50
<1
5/6
1.0
GFH48K3FI
220-240,1,50
<1
5/6
1.0
GTH48K3FI
220-240,1,50
<1
5/6
1.0
GFH60K3FI
220-240,1,50
<1
5/6
1.0
GTH60K3FI
220-240,1,50
<1
5/6
1.0
Notes:
RLA: Rated load amperes
LRA: Locked rotor amperes
FLA: Full load current
①
Install the disconnect device with a contact gap of at least 3mm in all poles nearby the units
(Both indoor unit and outdoor unit).The appliance must be positioned so that the plug is
accessible.
②
The specifications of the breaker and power cable listed in the table above are determined based
on the maximum power (maximum amps) of the unit.
③
The specifications of the power cable listed in the table above are applied to the conduit-guarded
multi-wire copper cable (like, YJV copper cable, consisting of PE insulated wires and a PVC
cable jacket) used at 40°С and resistible to 90°С (see IEC 60364-5-52). If the working condition
