Gree GUD160W/NhB-X User Manual

DC Inverter U-match Series Duct Type Unit
6
2.2 Operating Range
Cooling Heating
Outdoor temperature DB(°C) -15~52 -15~24
Indoor temperature DB/WB(°C)(Maximum) 32/23 27/-
2.3 Standard Accessories
Indoor Unit Accessories
No.
Name
Appearance
Q'ty
Usage
1 Wired Controller 1 To control the indoor unit
2 Nut with Washer 4
To fix the hook on the
cabinet of the unit
3
Hanger
or
4
To f ix t h e in do or un i t
(Only for GUD160PHS/B-S
and GUD160PH/B-S)
4 Nut
4
To be used together with the
hanger bolt for installing the
unit
5 Washer
4
To be used together with the
hanger bolt for installing the
unit
6 Insulation
1 To insulate the gas pipe
7 Insulation 1 To insulate the liquid pipe
8 Fastener 8 To fasten the sponge
9 Sponge 2 To insulate the drain pipe
10 Sponge
1
To insulate the Fresh air
inlet (Only for
GUD100-140PH/B-S and
GUD100-140PHS/B-S)
11
Removal-Proof
Screw Nut
or Ordinary Nut+
Ta m pe rp ro o f
box
or
+
1
To p re ve n t th e re m ov a l of
the gas pipe connecting nut
(Refer to the fittings included
in delivery)
