Gree GUD36W/A-D User Manual

DC Inverter U-match Series for R410A Unitary Split Air Conditioner
5
2 Product Introduction
2.1 Operating Range
ü
Cooling Heating
Outdoor
temperature
5
q
F(-15°C)~118.4
q
F (48°C) -22
q
F (-30°C)~75.2
q
F (24°C)
2.2 Standard Accessories
Outdoor unit accessories
No. Name Appearance Q'ty Usage
1 Drain plug
3
To plug the unused drain
hole
2
Drainage
connecter
or
1
To connect with the hard
PVC drain pipe
2.3 Optional Accessories
Outdoor unit accessories
No. Name Appearance Q'ty Usage
1
Throw-over
pipe
1
Connect the
unit with the
liquid pipe
2
Throw-over
pipe
1
Connect the
unit with the
gas pipe
3 Installation
3.1 Installation Preparation
3.1.1 Selection of Installation Location
ķ. The unit must be installed where strong enough to withstand the weight of the
unit and fixed securely, otherwise the unit would topple or fall off.
ĸ. Install the air conditioner at a place where the inclination is less than 5°.
Ĺ. Do not install the unit at a place with direct sunlight.
ĺ. Do not install where there is the danger of combustible gas leakage.
Ļ. Do not install the unit at a place with leakage of inflammable gas.
