(WPEVKQPCPF%QPVTQN
21
22
23
24
20
Up & down swing icon:
is displayed when pressing the up & down swing button. Press this button again to clear the display.
Left & right swing icon:
is displayed when pressing the left & right swing button.Press this button again to clear the display.
SET TIME display:
After pressing TIMER button, ON or OFF will blink.This area will show the set time.
DIGITAL display:
This area will show the set temperature. In SAVE mode,"SE" will be displayed. During defrosting operation, “H1” will be displayed.
FAN SPEED display:
Press FAN button to select the desired fan speed setting(AUTOLow-Med-High).Your selection will be displayed in the LCD windows,
except the AUTO fan speed.
1
2
3
4
5
6
7
8
ON/OFF:
Press this button to turn on the unit. Press this button again to turn off the unit.
MODE:
Each time you press this button,a mode is selected in a sequence that goes from AUTO, COOL,DRY, FAN, and HEAT *, as the
following:
*Note: Only for models with heating function.
After energization, AUTO mode is defaulted. In AUTO mode, the set temperature will not be displayed on the LCD, and the unit will
automatically select the suitable operation mode in accordance with the room temperature to make indoor room comfortable.
+ :
Press this button to increase set temperature. Hold it down for above 2 seconds to rapidly increase set temperature. In AUTO mode,
set temperature is not adjustable.
-:
Press this button to decrease set temperature. Hold it down for above . 2 seconds to rapidly decrease set temperature. In AUTO
mode, set temperature is not adjustable.
FAN :
This button is used for setting fan speed in the sequence that goes from AUTO, , , to then back to Auto.
●Press button to start or stop up & down swing function.The remote controller defaults to simple swing condition.
●Press + button and button at the same time at unit OFF to switch between simple swing and static swing; blinks for 2
seconds.
●In static swing condition, pressing button, the swing angle of up & down louver changes as below:
●If the unit is turned off during swing operation,the louver will stop at present position.
HEALTH SAVE:
Press HEALTH part of this button to turn on or off HEALTH function.Pressing SAVE part of this button,"SE" is displayed and the unit
goes into SAVE operation mode. Press SAVE part of the button again to cancel SAVE function. During SAVE operation, the temp-
erature and fan speed is not adjustable.
●Press button to start or stop left & right swing function.The remote controller defaults to simple swing condition.
●Press + button and button at the same time at unit OFF to switch between simple swing and static swing; blinks for 2
seconds.
AUTO
COOL DRY FAN HEAT*AUTO
Low speed Medium speed High speed
OFF
Remote controller description
To Next Page
