57
9. Troubleshooting
9.1 Precautions before Performing Inspection or Repair
Take sufficient care to avoid directly touching any of the circuit parts without first turning off the power.
At times such as when the circuit board is to be replaced, place the circuit board assembly in a vertical position.
Normally,diagnose troubles according to the trouble diagnosis procedure as described below.(Refer to the check points in servicing
written on the wiring diagrams attached to the indoor/outdoor units.)
Precautions when inspecting the control section of the outdoor
unit:
A large-capacity electrolytic capacitor is used in the outdoor unit controller
(inverter).Therefore,if the power supply is turned off,charge(charging volt-
age DC280V to 380V)remains and discharging takes a lot of time.. After
turning off the power source,if touching the charging section before
discharging, an electrical shock may be caused.
9.2 Confirmation
(1)Confirmation of Power Supply
Confirm that the power breaker operates(ON) normally;
(2)Confirmation of Power Voltage
Confirm that power voltage is AC 208~230 ± 10%.
If power voltage is not in this range, the unit may not operate normally.
9.3 Judgement by Flashing LED of Indoor/Outdoor Unit
Troubleshooting
No. Troubleshooting procedure
1Confirmation
2 Judgement by Flashing LED of Indoor/Outdoor Unit
3 How to Check simply the main part
Be cautious during installation and maintenance. Do operation following the
regulations to avoid electric shock and casualty or even death due to drop
from high attitude.
* Static maintenance is the maintenance during de-energization of the air
conditioner.
For static maintenance, make sure that the unit is de-energized and the plug
is disconnected.
*dynamic maintenance is the maintenance during energization of the unit.
Before dynamic maintenance, check the electricity and ensure that there is ground wire on the site. Check if there is electricity on the housing and
connection copper pipe of the air conditioner with voltage tester. After ensure insulation place and the safety, the maintenance can be performed.
The outdoor unit can not be started up until the unit is de-energized for 20min
