Super Free Match
Service Manual
INSTALLATION95
5.5 Outline Dimension and Servicing Space of FXB5A-K
1) Outline dimension
Sorts Indoor unit side (mm) Outdoor unit side (mm)
Liquid pipe Φ6.35 Φ9.52
Gas pipe Φ9.52 Φ15.9
2) Installation and service space
NO. ① ② ③
Name Servicing space Ceiling Electrical box side
