20
Installation and Maintenance
Service Manual
7. Installation
7.1 Installation Dimension Diagram
Space to the ceiling
Space to the wall
At least 15cm
At least 15cm
At least 15cm
At least 250cm
Space to the wall
Space to the obstruction
ro
olf
e
h
t
ot
eca
pS
Drainage pipe
At least 300cm
