Gree GWH(09)KF-K3DNA6E/I User Manual

2
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Model
GWH(07)KF-K3DNA6E/I
GWH(07)KF-K3DNA8E/I
GWH(07)KF-K3DNB4E/I
GWH(07)KF-K3DNB1E/I
GWH(07)KF-K3DNA5E/I
GWH(07)KF-K3DNB2E/I
GWH(09)KF-K3DNA6E/I
GWH(09)KF-K3DNB1E/I
GWH(09)KF-K3DNA5E/I
GWH(09)KF-K3DNA6E/I
GWH(09)KF-K3DNB2E/I
Product Code
CB146N26201
CB146N32800
CB146N33300
CB146N30000
CB146N35500
CB409N01400
CB146N26301
CB146N30100
CB146N28301
CB146N26302
CB409N01100
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Cooling Capacity KW 2.1 2.6
Heating Capacity KW 2.6 2.8
Air Flow Volume (SH/H/M/L) m
3
/h 550/520/370/280 600/520/370/280
Dehumidifying Volume L/h 0.6 0.8
Fan Type Cross-ow Cross-ow
Fan Diameter-height mm Φ92X594 Φ92X594
Fan Motor Speed (SH/H/M/L) Cool rpm 1350/1100/900/700 1350/1100/900/700
Fan Motor Speed (SH/H/M/L) Heat rpm 1350/1140/980/820 1350/1140/980/820
Fan Motor Power Output W 10 10
Fan motor running current A 0.16 0.16
Fan Motor Capacitor μF 1.2 1.2
Evaporator Material Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm 7 7
Evaporator Number of Rows 2 2
Evaporator Fin Pitch mm 1.4 1.4
Evaporator Length(L) X Height(H) X Width(W) mm 610X25.4X294 610X25.4X294
Motor Model FN10V-PG FN10V-PG
Overload Protector 3.15 3.15
Motor Full Load Amp(FLA) A 0.16 0.16
Sound Pressure Level (SH/H/M/L) dB (A) 40/38/30/24 41/38/30/24
Sound Power Level (SH/H/M/L) dB (A) 50/48/40/34 51/48/40/34
Outline Dimension (WXHXD) mm 770X283X201 770X283X201
Package Carton Dimension (LXWXH) mm 844X342X261 844X342X261
Package Dimension (LXWXH) mm 847X345X276 847X345X276
Net Weight kg 8 8
Gross Weight kg 10 10
Liquid Pipe mm Φ6 Φ6
Gas Pipe(to Indoor Unit) mm Φ9.52 Φ9.52
