Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model
GWH07AAA-K3NNA1A
GWH07AAA-K3NNA2A
GWH09AAB-K3NNA1A
GWH09AAB-K3NNA2A
Product Code
CA115013600
CA115014000
CA115013700
CA115013900
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity W 2200 2638
Heating Capacity W 2300 2755
Cooling Power Input W 685 821
Heating Power Input W 637 763
Cooling Power Current A 3.5 4.0
Heating Power Current A 3.2 3.5
Rated Input W 1050 1150
Rated Current A 5.5 5.6
Air Flow Volume(SH/H/M/L/SL) m
3
/h 470/420/370/250/- 570/500/430/300/-
Dehumidifying Volume L/h 0.6 0.8
EER W/W 3.21 3.21
COP W/W 3.61 3.61
SEER W/W / /
HSPF W/W / /
Application Area m
2
10-16 12-18
Indoor Unit
Model of Indoor Unit
GWH07AAA-K3NNA1A/I
GWH07AAA-K3NNA2A/I
GWH09AAB-K3NNA1A/I
GWH09AAB-K3NNA2A/I
Product Code of Indoor Unit
CA115N13600
CA115N14000
CA115N13700
CA115N13900
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ92X505 Φ93X580
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1300/1200/1100/850/- 1300/1200/1100/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min 1200/1100/1000/900/- 1250/1150/1050/900/-
Output of Fan Motor W 10 20
Fan Motor RLA A 0.15 0.22
Fan Motor Capacitor μF 1 1
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7.94 Φ7.94
Row-n Gap mm 1-1.2 1-1.2
Coil Length (LXDXW) mm 508X19.05X254 583X19.05X264
Swing Motor Model MP24AN MP24AN
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 40/38/35/27/- 40/37/35/27/-
Sound Power Level (SH/H/M/L/SL) dB (A) 50/48/45/37/- 50/47/45/37/-
Dimension (WXHXD) mm 698X250X185 773X250X185
Dimension of Carton Box (LXWXH) mm 742X306X244 817X306X244
Dimension of Package (LXWXH) mm 747X322X255 822X322X255
Net Weight kg 7.5 8.5
Gross Weight kg 8.5 9.5

Gree GWH07AAA-K3NNA1A Specifications

General

Brand	Gree
Model	GWH07AAA-K3NNA1A
Category	Air Conditioner
Language	English
