110
Installation and Maintenance
Service Manual
1.Remove handle
handle
2.Remove top panel
top panel
3.Remove front side panel
front side panel
Remove the screws connecting the top
panel with the front panel and left&right
side plate, and then remove the top panel.
valve cover
Loosen the screws connecting the front side
panel and chassis. Remove the front side
panel.
Steps Procedure
Twist off the screws used for fixing the handle and
v
alve cover
,
pull the handle and v
alve cover
up
ward to remove it.
18/24K
