89
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
GWH18QE-S6DBD6B/I GWH24QE-S6DBD6A/I
Product Code CB460N06800 CB460N07100
1
Front Panel Assy 200003000023S 200003000023S 1
2
Filter Sub-Assy 1101200703 1101200703 2
3
Screw Cover 2425245301 2425245301 3
4
Front Case Assy 00000200043 00000200043 1
5
Swing Lever 10512743 10512743 1
6 Air Louver 1 10512741 10512741 2
7 Helicoid Tongue sub-assy 26112384 26112384 1
8
Left Axile Bush 10512037 10512037 1
9
Rear Case assy 22202736 22202736 1
10
Rubber Plug (Water Tray) 76712012 76712012 1
11
Ring of Bearing 26152025 26152025 1
12
O-Gasket sub-assy of Bearing 76512051 76512051 1
13 Cross Flow Fan 10352057 10352057 1
14
Evaporator Support 24212178 24212178 1
15
Evaporator Assy 01100100007301 011001000095 1
16
Wall Mounting Frame 01252229 01252229 1
17
Motor Press Plate 26112515 26112515 1
18
Fan Motor 15012136 15012136 1
19
Connecting pipe clamp 26112514 26112514 1
20
Drainage Hose 0523001405 0523001405 1
21 Stepping Motor 1521240212 1521240212 1
22 Crank 73012005 73012005 1
23 Air Louver 1 10512742 10512742 1
24
Air Louver 10512744 10512744 1
25
Stepping Motor 1521210704 1521210704 1
26
Guide Louver 1051232001 1051232001 1
27
Axile Bush 10542036 10542036 2
28
Electric Box 2011221105 2011221104 1
29
Terminal Board 42011233 42011233 1
30
Electric Box Cover 2 20112210 20112210 1
31
Main Board 300002061087 300002060785 1
32
Display Board 300001000042 300001000042 1
33
Shield Cover of Electric Box 01592139 01592139 1
34
Electric Box Cover 20112209 20112209 1
35
Jumper 4202021928 4202021921 1
36
Lower Shield of Electric Box 01592139 01592139 1
37
Electric Box Assy 100002068643 100002068639 1
38
Power Cord / / /
39
Connecting Cable 4002052317 4002052317 0
40
Connecting Cable / / /
41
Temperature Sensor 3900031302 3900031302 1
42
Remote Controller 305001000139 305001000081 1
43 Cold Plasma Generator 1114001602 1114001602 1
44 Detecting Plate 30110144 30110144 1
Above data is subject to change without notice.
