Installation and Maintenance
Service Manual
No.
Description
Part Code
Qty
GWH09ACC-S6DBA1A/O GWH12ACC-S6DBA1A/O
Product Code CB497W09200 CB497W10000
1 Front Grill 22413046 22413046 1
2 Cabinet 0153305105 0153305105 1
3 Brushless DC Motor 1501308519 1501308519 1
4 Clapboard Sub-Assy 01235094 01235094 1
5 Chassis Sub-assy 017000060317P 017000060383P 1
6 Compressor and Fittings 00900100022901 00900100022901 1
7 Valve Support Sub-Assy 01710400005P 01710400005P 1
8 Cut-off valve 1/4(N) 07130239 07130239 1
9 Cut-off valve 3/8(N) 071302391 071302391 2
10 Valve Cover 22243005 22243005 1
11 Left Side Plate 01303169P 01303169P 1
12 4-Way Valve Assy 030152060290 030152060290 1
13 Filtering Sub-Assy 030184000056 030184000042 1
14 Condenser Assy 011002060644 011002000422 1
15 Fixed Mount 01207800008 01207800008 1
16 Flash Vaporizer Assy 030070060008 030070060008 1
17 Coping 012049000006P 012049000006P 1
18 Main Board 300027060797 300027060800 1
19 Electric Box Assy 100002065314 100002065683 1
20 Motor Support Sub-Assy 01703237 01703180 1
21 Left Side Plate 01303169P 01303169P 1
22 Axial Flow Fan 10333011 10333011 1
23 Valve Cover 22243005 22243005 1
24 Terminal Board 422000060016 422000060016 1
25 Wire Clamp 71010003 71010003 1
26 Wire Clamp 71010103 71010003 1
27 Compressor Gasket 009012000026 009012000026 3
Above data is subject to change without notice.
