Installation and Maintenance

Service Manual

No.

Description

Part Code

Qty

GWH24YE-S6DBA2A/O GWH18ACE-S6DBA1A/O

Product Code CB466W00300 CB497W11000

1 Front Grill 22415011 22415011 1

2 Fan Motor 15010400000106 15010400000102 1

3 Electric Box (Fireproong) 20115003 20115003 1

4 Radiator 4901521501 4901521501 1

5 Main Board 300027000308 300027060855 1

6 Electric Box Assy 100002000609 100002066754 1

7 Terminal Board Support sub-assy 01715016 01715016A 1

8 Terminal Board 422000060009 422000060009 1

9 Handle 26233053 26233053 1

10 Left Side Plate 01305043P 01305043P 1

11 Coping 01255020P 01255020P 1

12 Motor Support Sub-Assy 017012000015 017012000017 1

13 Condenser Support Plate 01175092 01175092 1

14 Clapboard Sub-Assy 017021000067 01235091 1

15 Condenser Assy 011002000285 011002000486 1

16 Rear Grill / / /

17 Wiring Clamp 26115004 26115004 1

18 Temp Sensor 3900030901 3900030901 1

19 Right Side Plate 0130504401P 0130504401P 1

20 Big Handle 26235001 26235001 1

21 Cut off Valve 07130239 07130239 1

22 Valve Support Sub-Assy 0170506101P 0170506101P 1

23 Bafe(Valve Support) 0170505701 0170505701 1

24 Electronic Expansion Valve 072009000019 072009000019 1

25 4-Way Valve Assy 030152000260 030152000260 1

26 Compressor and Fittings 00105274 00105274 1

27 Drainage Connecter 06123401 / 1

28 Chassis Sub-assy 017000000166P 017000060398P 1

29 Drainage hole Cap 06813401 / 1

30 Axial Flow Fan 10335013 10335013 1

31 Cabinet 01435004P 01435004P 1

32 Valve Cover 22245003 22245003 1

Above data is subject to change without notice.
