Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model GWC24ATEXF-D3DNA1E GWH24ATEXF-D3DNA1E
Product Code CB574002400 CB574002500
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 22000 22000
Heating Capacity Btu/h / 24000
Cooling Power Input W 1896 1896
Heating Power Input W / 2051
Cooling Current A 8.5 8.5
Heating Current A / 9.5
Rated Input W 2400 2400
Rated Current A 12 12
EER (Btu/h)/W 11.6 11.6
COP (Btu/h)/W / 11.7
SEER 18(SEER) 18(SEER2) 18(SEER) 18(SEER2)
HSPF / 10(HSPF) 8.5(HSPF2)
Air Flow Volume CFM 677/589/559/500/471/441/412 677/589/559/500/471/441/412
Dehumidifying Volume Pint/h 5.28 5.28
Application Area yd
2
28-41 28-41
Indoor Unit
Indoor Unit Model GWC24ATEXF-D3DNA1E/I GWH24ATEXF-D3DNA1E/I
Product Code of Indoor Unit CB574N02400 CB574N02500
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф111.5X830 Ф111.5X830
Cooling Speed r/min 1350/1200/1100/1000/950/900/850 1350/1200/1100/1000/950/900/850
Heating Speed r/min / 1350/1200/1100/1000/950/900/850
Fan Motor Power Output W 45 45
Fan Motor RLA A 0.45 0.45
Fan Motor Capacitor μF / /
Heater Power Input W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф7 Ф7
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 840X25.4X381 840X25.4X381
Swing Motor Model MP35CP MP35CP
Swing Motor Power Output W 2.5 2.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 51/47/45/42/40/38/36
Cooling: 51/47/45/42/40/38/36
Heating: 52/48/45/42/40/38/37
Sound Power Level dB (A) 61/57/55/52/50/48/46
Cooling: 61/57/55/52/50/48/46
Heating: 62/58/55/52/50/48/47
Dimension (WXHXD) inch 42 7/16X13 7/64X9 11/16 42 7/16 X13 7/64 X9 11/16
Package Carton Dimension
(LXWXH)
inch 44 13/32X15 63/64X12 23/32 44 13/32 X15 63/64X12 23/32
Package Dimension (LXWXH) inch 44 39/64/32X16 19/64X13 7/64 44 39/64/32X16 19/64X13 7/64
Net Weight Ib 33.1 33.1
Gross Weight Ib 39.7 39.7

Gree GWH12ATCXB-A3DNA3C Specifications

General

Brand	Gree
Model	GWH12ATCXB-A3DNA3C
Category	Heat Pump
Language	English
