2. Specications
2.1 Specication Sheet
Model GWH09MB-K3DNA4K GWH09MB-K3DNA5K
Product Code CB161005902 CB162006702
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity (Min~Max) W 2700(600~3200) 2700(600~3200)
Heating Capacity (Min~Max) W 2800(800~3600) 2800(800~3600)
Cooling Power Input (Min~Max) W 870(185~1300) 870(185~1300)
Heating Power Input (Min~Max) W 900(220~1400) 900(220~1400)
Cooling Power Current A 3.8 3.8
Heating Power Current A 3.92 3.92
Rated Input W 1400 1400
Rated Current
A
6.69 6.69
Air Flow Volume(SH/H/M/L/SL) m
3
/h 600/500/400/300/- 600/500/400/300/-
Dehumidifying Volume L/h
0.8
0.8
EER W/W 3.10 3.10
COP W/W 3.11 3.11
SEER
W/W
5.6 5.6
HSPF W/W 3.8 3.8
Application Area m
2
12-18 12-18
Indoor
Unit
Model of Indoor Unit
GWH09MB-K3DNA4K/I
GWH09MB-K3DNA5K/I
GWH09MB-K3DNA4K/I
GWH09MB-K3DNA5K/I
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Φ92X645 Φ92X645
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1260/1050/900/690/- 1260/1050/900/690/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min 1320/1200/1000/910/- 1320/1200/1000/910/-
Output of Fan Motor W 20 20
Fan Motor RLA A 0.1 0.1
Fan Motor Capacitor μF 1.0 1.0
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 636X25.4X267 636X25.4X267
Swing Motor Model MP24AA MP24AA
Output of Swing Motor W 2 2
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 41/39/34/28/- 41/39/34/28/-
Sound Power Level (SH/H/M/L/SL) dB (A) 54/50/45/40/- 54/50/45/40/-
Dimension (WXHXD) mm 845X275X180 845X275X180
Dimension of Carton Box (LXWXH) mm 915X255X355 915X255X355
Dimension of Package (LXWXH) mm 918X258X370 918X258X370
Net Weight kg 9 9
Gross Weight kg 12 12
