Gree GWHN09AANK3A1A User Manual

Part Code
GWHN24ACNK3A1A/O
1
Front Grill
22265251
1
2
Front Plate
01433017P
1
3
Axial Flow Fan 10335257
1
4
Motor LW68B 15015057
1
5
Motor Support 01703027
1
6
Condenser Assy. 01113054
1
7
Temp Sensor Support 24215101
1
8
Temp Sensor 390002063
1
9
Top Cover 01255262
1
10
Rear Grill 01473028
1
11
Electric Box Top Plate 01413076
1
12
Electric Box As sy
01403902
1
13
CBB65 60uF/450V φ 33000039
1
14
Capacitor CBB61 33010026
1
15
Main PCBW5102CJ
30135198
1
16
Transformer41X26.5G 43110236
1
17
Terminal Board 42010258
1
18
4-way Valve Coil
430004002
1
19
4-way Valve
430004032
1
20
Temp Sensor 3900012121
1
21
Handle 26235253
3
22
Gas Valve Assy. 07105252
1
23
Liquid Valve Assy 071302391
1
24
Rear Side Plate 01305036
1
25
Valve Support 01715001
1
26
Capillary Tube Assy. 03103565
1
27
Compressor 5VS245EAA21 00103034
1
28
Overload Protection
--
1
29
Insulation Cushion
70410523
1
30
Isolation Sheet Assy. 01233024
1
31
Capacitor Clamp 02141005
1
32 AC Contactor CJX9B-25S/00
44010245
1
33 Chassis
01203628P
1
34
Front Side Plate 01303023
1
No Description Qty
Artful
The above data are subject to change without prior notice.
Parts List of Outdoor Unit (3)
