7
INSTALLATION SCHEMATIC
Indoor unit
Outdoor unit
5
Air outlet
Air inlet
Air inlet
Air outlet
3
4
1
2
6
7
8
* Not all items in this schematic are
included with equipment purchase
Installation Components*
1. Front Panel
2. Aux. Button
3. Air Filter
4. Horizontal Louver
5. Remote Controller
X41 Wired Tether Controller
(Not shown-sold separately)
6. Inter-Connecting Wire (sold separately)
7. Drain Hose (sold separately)
8. Refrigerant Lines (sold separately)
