Translation of the Original Instructions
IDENTIFICATION AND SERVICING
IDENTIFICATION
The vehicle’s serial number is punched on the
nameplate on the left-hand longitudinal
member of the chassis and on the gearbox
nameplate. Always state the serial number
when ordering spare parts.
AFTER-SALES SERVICE
This manual provides instructions on how to use the walking tractor and to carry out a basic
maintenance which the user can carry out personally. For all procedures not described in this
manual, contact your local dealer.
SPARE PARTS
Always use original spare parts, as they are the only ones to ensure complete safety and
interchangeability. Always state the serial number when ordering spare parts. For engine parts,
refer to the specific manual.
WARRANTY
The guarantee is given in compliance with the current law. The Grillo dealer will supply the client
with a copy of the registration card of the machine, which they will print from the Grillo website. For
the engine, the guarantee of the relative manufacturers apply.
ORDERING SPARE PARTS
Always state the machine serial number and the code number of the part to be replaced. Contact
your local dealer. Our address is:
GRILLO S.p.A.
Via Cervese 1701 - 47521 CESENA (FC) - ITALY
Tel. 0039 / 0547 / 633111 - Fax 0039 / 0547 / 632011
Web site: www.grillospa.it - E-mail: grillo@grillospa.it
TECHNICAL SPECIFICATIONS G85 – G85D
ENGINES
ROBIN SUBARU EX 27 petrol engine
LOMBARDINI 15LD350 diesel engine
Also available with electric starter.
MACHINE
Clutch: active clutch.
Gearbox: 4 speeds – 2 forward + 2 reverse both as rotavator and as sickle-bar (turning the
handlebars).
Speeds in km/h with engine at 3600 r.p.m. are as follows:
Gears Speeds with tyres 4.00-8
Ist
IInd
Ist REVERSE
IInd REVERSE
1,1
2,6
1,1
2,6
P.T.O.: independent from the gearbox; 965 rpm with engine at 3600 rpm.
Wheels: tyres 4.00-8 /4.00-10 /5.00-10.
Rotary tiller: 58 cm standard; adjustable up to 37-47-68 cm.
Handlebar: Side and height adjustment –
