GW Instek GPT-9000 series Quick Start Guide

OPERATION
15
Choose AUTO Number and MANU Number
(AUTO mode)
 Use the UP/DOWN cursors to highlight either the
AUTO number (automatic test) or MANU number
(step).
 Use the scroll wheel to select the AUTO/MANU
number.
Go to EDIT Status
 Press the EDIT/SAVE key.
EDIT/SAVE
Go to READY Status
 Press the STOP button when a MANU test or AUTO
test has been selected.
STOP
AUTO/MANU Mode
Description
MANU mode is used to create and execute
manual tests. The MANU mode is also used to
access the Special MANU mode.
AUTO mode is used to create automatic tests
that execute up to 16 steps (manual tests)
sequentially.
G
B
I R A CW D C W
E
F R E Q = 0 H z 6
0 100
k V
EIV
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
A U T O = 0 0 1 - 0 0 2
W
MM A UN N A_2M A N U = * * * - 0 0
AUTO mode
MANU mode
m A
