- 35 -
Service Manual
Model No.: 48E2500
8-3 Wiring Connection Diagram
No. Connection
1 Connection wire for keypad
2 Connection wire for IR LED
3 Connection wire for speakers
4 LVDS wire
5 Connection wire for power
1
3
2
4
5
