Service Manual
Model No.: 48E2500
- 8 -
3. Location of Controls and Components
3-1 Component Location
3-2 Main Board
No. Component
1
LED Panel
2
System Main Board
3
4
Keypad and IR Line
5
Panel T-Con Board
6
Keypad Board
7
IR LED Board
1
2
3
4
5
6
7
/9'6/LQH
