SERVICE MANUAL
Model: BD-379GAA
10
Issue 2009-12-14
Rev.
Ref0912S018V0
Chapter 4 Disassembly
4-1. Door assembly (Door, hinge, hinge cover)
Disassemble the hinge assembly and the hinge cover: the hinge cover, take away the cover, and then
screw off the eight screws on the bottom hinge, so the whole hinge could be moved.
4.2. Compartment Grill assembly
Unscrew the two screw of grill; you can take away the grill.
To Next Page
