FlexFit Pro
High Effciency
DC Fan Motor
Achieves higher efciency as compared to a conventional
AC motor. See chart.
Comfortable
Consistent Air Flow
Up to 3 fans maintain desired air volume as static pressure
changes.
Slim Design
10" cabinet height means easier installation in a wide variety
Return Air Options
Installer-friendly design; choose rear or bottom return
conguration.
1. Features
20
0
200 400 600 800 1000
40
60
80
100
40%
35%
25%
20
0
200 400 600 800 1000
40
60
80
100
90%
87.5%
85%
Torque(kgfcm)
Rev(r/min)
AC motor efficiency DC motor efficiency
Rev(r/min)
Torque(kgfcm)
120Pa
100Pa
70Pa
50Pa
Air Flow
2500
2000
50po 70po 100po 120po
ESP
1500
2500
100%
m/h³
2500
100%
m/h³
2500
100%
m/h³
2500
100%
m/h³
100% airflow when the ESP
reach 120pa for Haier duct
Air Flow
2500
2000
50po 70po 100po 120po
ESP
1500
100%
2500
m/h³
90%
2250
m/h³
76%
1900
m/h³
68%
1700
m/h³
Oniy 68% airflow when the ESP
reach 120pa for traditional duct
Common
250
250
mm
250
mm
Rear air return
Bottom air return

Haier FlexFit Pro 1U24LP2VHA Specifications

General

Brand	Haier
Model	FlexFit Pro 1U24LP2VHA
Category	Air Conditioner
Language	English
