Français | 21
DIAGRAMME DU CIRCUIT ÉLECTRIQUE
K1 Interrupteur de la porte HP Pompe à chaleur
K2 Interrupteur du niveau d'eau DP Pompe de vidange
H Capteur d'humidité L Lampe
NTC1 Capteur de température F Moteur de ventilation
NTC2 Capteur de température M Moteur
NTC3 Capteur de température
K1 H K2 NTC1 NTC2 NTC3
HP
DP L F
N
L
G
PCB
M
