Haier HDW101SS User Manual

7
2
1
4
3
6
5
When the low rinse aid indicator lights, you must load rinse aid.
Rinse aid
This product makes dishes sparkle and helps them to dry without spotting. The dispenser is located on
the inside panel of the door .
Loading the rinse aid
Regardless of the type of detergent dispenser installed on your appliance,
you must proceed as indicated below when loading the rinse aid.
To open the dispenser, turn the "1" cap in an anti-clockwise direction
and then pour in the rinse aid, making sure not to overfill. The amount
of rinse aid used for each cycle can be regulated by turning the "2"
dose adjustor, located beneath the "1" cap, with a screwdriver. There
are 6 different settings; the normal dosage setting is 1.
Important
Proper dosage of the rinse aid improves drying.
If drops of water remain on the dishes or spotting occurs, the dosage adjustor should be
turned to a higher setting.
If the dishes have white streaks, turn the dosage adjustor to a lower setting.
How to fill the rinse aid and the detergent dispenser
Detergent
Detergent specifically intended for use with dishwashers must be used.
The dispenser must be refilled before the start of each wash cycle
following the instructions provided in the "Programme overview". The
detergent dispenser is located on the inside panel of the door.
To open the "3" cover on the dispenser, press the "4" button.
The detergent for the wash cycle should be poured into the "5"
compartment.
The detergent for the pre-wash cycle should be poured into the
“6” compartment.
After the detergent has been placed in the dispenser, close the
cover and press down until it clicks in place.
Loading the detergent
Notice:
To facilitate closing the cover, remove any excess detergent on the edges of the dispenser.
Dishwasher detergents are stronly alkaline. They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep children away from the dishwasher when the
door is open. Check that the detergent receptable is empty after completion of the wash
cycle.

Haier HDW101SS Specifications

General

Type	Freestanding
Capacity	10 place settings
Energy Efficiency	A+
Wash Cycles	6
Noise Level	49 dB
Color	Stainless Steel
Control Type	Electronic
Energy Rating	A+
Child Lock	Yes
Dimensions	845 x 598 x 600 mm
Programs	Intensive, Normal, Eco, Glass
Delay Start	Yes

Summary

Safety Information

During installation

During normal use

Adult use only; avoid tipping, drinking water, solvents, or touching heating elements.

If a fault occurs

Turn off water, disconnect power, and contact service for repairs.

Installation

Positioning and Levelling

Water Connections

Electrical Connection

Connect to an earthed socket; ensure plug accessibility for maintenance.

Filling Rinse Aid and Detergent

Rinse Aid Dispenser

Detergent Dispenser

Loading the Dishwasher

Lower Rack Loading

Position pots, pans, and lids face down or angled.

Upper Rack Loading

Place delicate items like glasses and cups, adjust rack height.

Washing Dishes

Programme Selection

Starting a Wash Cycle

Steps to begin a wash cycle: plug in, turn on water, load, add detergent.

Cycle Adjustment and End

Dishwasher Care and Maintenance

After Each Wash

Regular Inspection

Fault Finding

Appliance Not Starting

Troubleshooting steps for when the appliance fails to power on.

Error Alarms

Interprets beep patterns for various operational issues like water or door problems.

Issues During Washing

Dish and Cutlery Problems

Solutions for food remnants, stains, poor drying, clouding, and rust.

Specific Dish Issues
