Haier HF71CM33NW User Manual

49-60793
10
FEATURES
ENGLISH
POWER ON INDICATOR - (HFC3501ACW, HF71CW20W
HF71CM33NW, HF71CL53NW only)
The Power On indicator illuminates when the freezer
is properly connected to electrical power.
IMPORTANT: Turning the control dial to OFF does not disconnect the
freezer from the power supply. Even when Cooling is turned Off, the Power
On indicator will remain illuminated as long as the freezer is plugged into an
outlet.
SLIDING BASKET
Store small packages in the basket to avoid losing
them in the bottom of the freezer. The basket can
be moved from side to side or it can be removed
when loading or unloading the food below it.
To remove basket, lift it straight up and out. To
replace basket, lower basket back into place.
FREEZER LOCK AND KEY (HF71CL53NW only)
IMPORTANT:
• Store the freezer key in a location away from the freezer and not easily
accessible to children.
• The key slot is spring loaded or equivalent so that the key must be
manually held in the lock in any position of the lock.
To Lock/Unlock the Freezer:
Close the freezer lid, insert the key, push in and turn the key to lock. To
unlock, insert the key, push in and turn the key in the opposite direction.
WARNING
To prevent a child from being entrapped, keep the key
out of reach of children and away from the freezer.
RECOMMENDED GROUNDING METHOD
A 115 Volt, 60 Hz, AC only, 15- or 20-amp fused, grounded electrical
supply is required. It is recommended that a separate circuit serving only
your freezer be provided. Use an outlet that cannot be turned off by a
switch. Do not use an extension cord.

Haier HF71CM33NW Specifications

General

Type	chest
Color	white
Total Capacity	7.1 cubic feet
Temperature	yes
Defrost System	manual
Quick Freeze	yes
Temperature Alarm	no
Temperature Control	adjustable
Interior Light	no
Child Lock	no
Smart Home	no
Annual Energy Consumption	248 kilowatt hours
Voltage	115 volts
Current	12 amperes

Weight and Dimensions

Depth	21.63 inches
Height	33.25 inches
Width	37 inches
Net Weight	83.3 pounds
