49-60793
14
LID REMOVAL
FREEZER CARE
ENGLISH
If it is necessary to remove the lid, follow these steps:
1. Remove the lower part of the hinge cover and then remove the upper
part.
2. Open the lid to the maximum position. (The hinges are loosest at this
position.)
3. Remove the 4 screws from the upper part of the hinge and the lid. Do
this for each of the 2 hinges.
4. To reinstall lid follow steps in reverse. Tighten all hinge screws but avoid
over-tightening to prevent stripping. Reinstall hinge covers.
CAUTION
LIFTING HAZARD
The lid is heavy. Use both hands to secure the lid before lifting.
Upper Hinge
Cover
Lower Hinge
Cover
Hinge Screws to
be Removed
CAUTION
HINGE SPRING UNDER TENSION

Other manuals for Haier HF71CM33NW

Questions and Answers:

Haier HF71CM33NW Specifications

General IconGeneral
Typechest
Colorwhite
Total Capacity7.1 cubic feet
Temperatureyes
Defrost Systemmanual
Quick Freezeyes
Temperature Alarmno
Temperature Controladjustable
Interior Lightno
Child Lockno
Smart Homeno
Annual Energy Consumption248 kilowatt hours
Voltage115 volts
Current12 amperes
Weight and Dimensions IconWeight and Dimensions
Depth21.63 inches
Height33.25 inches
Width37 inches
Net Weight83.3 pounds
