Step 1
Installing the Bottom Panel
The bottom panel blocks noises to provide you with the quietest performance
possible during the wash cycle operation.
1. First, lay down the washer on its front side.
2. Place the panel against the bottom of the machine.
Align the holes in the panel with the holes in the
washer.
3. Insert the screws through the holes of the
panel into the bottom of the washer and
tighten. (6 screws are supplied)
4. Once all screws have been installed
and the panel is in place, return the
washer to its standing position.
Note: During this time, you may reroute the drain hose to the left or right side
for draining. Just remove hose clamp and snake to other side, then re
insert hose to other side
