Haier HSU-09HEG03/R2(DB) Service Manual

Wiring Diagrams
29
Domestic Air Conditioner
--- 24 Overcurrent of the compressor
--- 25 Overcurrent protection for single-phase of the compressor
---- 36 The socket protect
5.3 Value of Thermistor
5.3.1 intdoor Unit
---- 19 Loop of the station detect error
E9 21 High work-intense protection
Room sensor and Pipe Sensor
R77 =10K 3%
B77
/122 =3700K 3%
F
FF
Temp.(℉)
Max.(KΩ) Normal(KΩ) Min.(KΩ)
-22 165.2170 147.9497 132.3678 28.51 35.15
-20 155.5754 139.5600 125.0806 28.53 35.13
Torlance(℉
)
-18 146.5609 131.7022 118.2434 28.56 35.11
-17 138.1285 124.3392 111.8256 28.60 35.08
-15 130.2371 117.4366 105.7989 28.63 35.06
-13 122.8484 110.9627 100.1367 28.67 35.04
-11 115.9272 104.8882 94.8149 28.71 35.01
-9 109.4410 99.1858 89.8106 28.74 34.99
-8 103.3589 93.8306 85.1031 28.76 34.95
-6 97.6556 88.7989 80.6728 28.80 34.93
-4 92.3028 84.0695 76.5017 28.83 34.92
-2 87.2775 79.6222 72.5729 28.87 34.88
0 82.5577 75.4384 68.8710 28.90 34.81
1 78.1230 71.5010 65.3815 28.94 34.83
3 73.9543 67.7939 62.0907 28.98 34.79
5 70.0342 64.3023 58.9863 29.01 34.77
7 66.3463 61.0123 56.0565 29.05 34.74
9 62.8755 57.9110 53.2905 29.08 34.72
10 59.6076 54.9866 50.6781 29.12 34.68
12 56.5296 52.2278 48.2099 29.16 34.65
12
56.5296
52.2278
48.2099
29.16
34.65
14 53.6294 49.6244 45.8771 29.19 34.63
